Seifert 48V 850 BTU Peltier Control Cabinet Thermoelectric Cooler, External


Seifert 48V 850 BTU Peltier Control Cabinet Thermoelectric Cooler, External
Seifert 3200310 48V 850 BTU Peltier Control Cabinet Thermoelectric Cooler, External

Alternative Views:


Price: $2,041.54
Note: Non-cancelable, non-returnable
MFG P/N: 3200310
MFG: Seifert
Weight (lbs): 30

Quantity in Stock :3


Availability:
In Stock
Product Code: 3200310
Qty:

Description


The Seifert 3200310 Peltier control cabinet thermoelectric cooler has a rated voltage of 48V DC with a cooling capacity of 850 BTU. The power consumption is 226W, with a max. power consumption of 360W. It is externally mounted with a stainless steel AISI 304 housing that withstands corrosion. Internal and external heat sinks cool the inside air and disperse the heat outside.

  • For indoor or outdoor use
  • Can work under demanding conditions
  • Requires no filters
  • Needs little to no maintenance
  • No compressor, no refrigerant
  • Ambient fan assists with heat transfer
  • Can be mounted vertically or horizontally
  • Comes with mounting frame

Specifications

  • Housing Material- Stainless Steel AISI 304 (V2A)
  • Cooling Capacity 95F/95F- 850 BTU
  • Temperature Range- -4 F - 149 F
  • Air Volume Flow- Ambient air circuit: 70 / 153 cfm, Cabinet air circuit: 70 / 153 cfm
  • Mounting- External
  • Dimensions- 19.7" Height x 7.4" Width x 6.9" Depth
  • Cut-out Dimensions- 18.5 x 6.1 in.
  • Torque for Mounting Nuts- 4.5 Nm
  • Rated Voltage- 48V DC
  • Nominal Current- 4.7 Amps
  • Starting Current- 9.5 Amps
  • Max Current- 7.5 Amps
  • Power Consumption- 226 Watts
  • Max Power Consumption- 360 Watts
  • Fuse Rating- 10 Amps (T)
  • Connection- Connection Terminal Block
  • Protection Category- IP 66 - Indicates total protection from dust & powerful water jets in any direction
  • Approvals- CE, C UR US, RoHS
  • Warranty- 2 Year Manufacturer's Warranty

Seifert TG 3200 Thermoelectric Cooler Downloads

User Manual

Seifert 3200310 48V DC 850 BTU External Thermoelectric Cooler
