This Sealcon M16 elongated female straight signal connector features a 3 pin insert for 2 mm contacts. The housing is nickel plated brass with brass alloy contacts. The housing can accept 5-9 mm cable. Rated IP67 / IP69K. Comes un-assembled with separate housing, insert, and crimp contacts. Note: Image is for reference, actual product may differ

• No tools needed to insert or remove contacts
• Euro-Lock keeps contacts in position
• EMI shielding
• Perfect for small drives

Includes:

• Housing - (1) 5-9 mm (.2"-.35") Cable O.D. (P/N S7.811.400.000)
• Insert - (1) 3 pin, 20 A, 400V, for crimp contacts (P/N S7.003.983.102)
• Contacts - (3) 17-14 AWG 2 mm Crimp Sockets (P/N S7.010.982.002)

Specifications

• Housing - Nickel Plated Brass
• Housing Dimensions- 2.01" Length x 0.77" Diameter
• Insert - PBT
• Contacts - Brass Alloy
• Contact Surface - Gold Plated Nickel
• Orientation - Female Straight
• Cable Range - 5 - 9 mm (.2"- .35")
• Contacts - 3
• Crimp Wire Gauge - 17-14 AWG
• Operating Temperature - -40 F to 257 F (-40 C to 125 C).
• Nominal Current- 20 Amps
• Nominal Voltage - 400 V
• Min. Mating Cycles- >1000
• Insulation Resistance - >10^10 MOhm
• Max. Contact Resistance - 3 mOhm
• Mating Thread - M16
• Type of Connection - Crimp Contact
• IP Protection - IP 67 / IP 69 K

Sealcon 3 Pole Elongated Female Straight 5-9 mm Cable Entry M16 Connector
