The Mencom MDE45P-4MP-2M Ethernet male straight cordset features a 4 pin insert with M12 D-coded mating thread and 2 meters of oil resistant teal PUR cable. The body is black PUR with gold plated copper alloy contacts. The MDE45P-4MP-2M has a rated voltage of 300V and a rated current of 3A. Rated IP 69. Operating temperature: -40 C to 80 C (-40 F to 176 F). Mencom Ethernet cordsets can be used for a number of different applications and are made for extreme environments.

Specifications

• Body- Black PUR
• Insulator- Polyamide
• Contacts- Gold Plated Copper Alloy
• Coupling Nut- Nickel Plated Brass
• Cable- 24 AWG Cat5e PUR
• Rated Voltage- 300 V
• Rated Current- 3 Amps
• Wire Gauge- 24
• Pin Count- 4
• Cable Length- 2 Meters (6.56 Feet)
• Cable OD- 0.24
• Ingress Protection- IP 69 (Total protection from dust as well as high pressure and high temperature water jets from any direction)
• Orientation Head- Male Straight
• Coupling Thread- Male
• Mating Thread / Type Head- M12 D-Code
• Nut- No
• Approvals- UL & CUL Listed

Mencom Ethernet Cordset Part Number Guide

Mencom MDE45P-4MP-2M M12 2 Meter Cable
