Home > Industrial Ethernet Connectors > Ethernet Cordsets >

Mencom Ethernet Cordset, 8 Pole, Female/RJ45, 10 Meter


Ethernet Cordset Female Straight / RJ45 Plug - MDE45-8FP-RJ45-10M
Mencom MDE45-8FP-RJ45-10M Ethernet Cordset, 8 Pole, Female/RJ45, 10 Meter

Alternative Views:


Price: $101.90
MFG P/N: MDE45-8FP-RJ45-10M
MFG: Mencom
Weight (lbs): 0.85



Availability:
In Stock
Product Code: MDE45-8FP-RJ45-10M
Qty:


Description


The Mencom MDE45-8FP-RJ45-10M Ethernet female straight molded cable features an 8 pin insert with M12 D-coded mating thread, an RJ45 plug and 10 meters of oil resistant teal PVC cable. The body is black PVC with gold plated copper alloy contacts. The MDE45-8FP-RJ45-10M has a rated voltage of 42V and a rated current of 1.5A. Rated IP 69. Operating temperature: -20 C to 80 C (-4 F to 176 F). Mencom Ethernet cable is made for harsh conditions and creates a reliable Ethernet connection.

Specifications

  • Body- Black PVC
  • Contacts- Gold Plated Copper Alloy
  • Coupling Nut- Nickel Plated Brass
  • Insert- Polyamide
  • Cable- 24/8 Cat5e Teal PVC
  • Rated Voltage- 42 VDC
  • Rated Current- 1.5 Amps
  • Wire Gauge- 24
  • Pin Count- 8
  • Cable Length- 10 Meters (32.8 Feet)
  • Cable OD- 0.22
  • Ingress Protection- IP 69 (Total protection from dust as well as high pressure and high temperature water jets from any direction)
  • Ethernet Cable Standard- Cat5e
  • Orientation Head 1- Female Straight
  • Orientation Head 2- RJ45 Plug
  • Coupling Thread 1- Female
  • Coupling Thread 2- RJ45 Plug
  • Mating Thread / Type Head 1- M12
  • Nut- No

Mencom Ethernet Cordset Part Number Guide

Mencom MDE45-8FP-RJ45-10M 8 Pin Female Ethernet Molded Cable
